Split Core Current Transformers

● Measurement: Alternating Current (AC)

● Accuracy: Class 0.5 ~ 1

● Primary Current Input:150~1000A AC

● Rated Frequency: 50~60Hz

● Installation: Split Type

● Standard&Certificate: CE, IEC, UL

WhatsApp: 8615000360686
E-mail: aliness@acrel.cn

manual.pdf
[UL Certificate].pdf

Description
DATA SHEET

Description

Acrel AKH-0.66 Series Split Current Transformer

The appearance is nice and the installation and wiring are convenient. AKH-0.66/K-Φ series split current transformers are mainly used in reconstructing projects of urban and rural power grids. The product has the advantages of small size, high accuracy, strong load capacity, easy installation, etc. They save manpower, material resources, and financial resources and improve the efficiency of users.

Split Core Open type

Easier for installation.

high accuracy for metering

Class 0.5 & Class 1

variable input and output

5A, 1A, 10mA, 20mA, 100mA

Acrel CT

Split-core current transformers are built primarily for power grid construction or retrofit projects, beautiful appearance, and convenient installation of split-core and wiring, and they are mainly used in power operations and electricity reconstruction projects.

Appearance

Split Core Current transformer

● Built-in input coil

● High Conductivity Nickel Magnetic Stell

● 5A/1A Output

● Split Core Open Type

CT steel

PVC Material

● Coil PVC Material

● High performance and stability

Parameter

product-1698-1560

How to use the current transformer?

how to install the CTs

Why Choose Us?

Acrel CO., Ltd

Free Technical Selection

Technical Guidance

Free Repair And Placement

Two Year Quality Warranty

Acrel Co., Ltd. [Stock Code: 300286. SZ] is a high-tech enterprise concentrating on research, production, sales, and services. It mainly provides systemic solutions for energy efficiency management and user electrical safety. Acrel is equipped with complete production lines from cloud platform software to sensors. Until now, it has over 8000 sets of systemic solutions used in China to help users realize energy visual management, supply energy data services, and improve electrical efficiency and safety.

We continually invest in new technology to enhance the performance of our current transformers.
The company is actively completing product restructuring and industrial optimization and upgrading, practicing new ideas, and constantly ushering in new and higher quality development.
Our current transformers are designed to provide accurate readings even in harsh environments.
It is our duty and mission to work hard for every customer to achieve the highest satisfaction with our products.
As a manufacturer and supplier of current transformers, we offer a wide range of products to meet our clients' needs.
The company has advanced equipment, strong technical force, reliable reputation, good service and flexible business operation.
Our current transformers are designed to be safe and reliable, with built-in precision and accuracy.
We actively develop relationships with well-known commercial authorities at home and abroad and continue to build a service system.
We are committed to providing our clients with exceptional service and high-quality products.
Our Split Core Transformer use advanced production technology and high-quality raw materials to ensure the quality of products from the source.

Model Name	Primary Input	Secondary Output	Accuracy Class	Rated Load	Perforation Hole Size (mm)
AKH-0.66/K-φ16-U	20~120A	100~333mV	0.5	10Ω	φ16
AKH-0.66/K-φ16-M	20~120A	10~50mA	0.5	10Ω	φ16
AKH-0.66/K-φ24-U	100~400A	100~333mV	0.5	10Ω	φ24
AKH-0.66/K-φ24-M	100~400A	10~100mA	0.5	10Ω	φ24
AKH-0.66/K-φ24-A	150~200A	5A	1.0	1VA	φ24
AKH-0.66/K-φ24-A	250A~300A	5A	1.0	1.5VA	φ24
AKH-0.66/K-φ24-B	150~200A	1A	1.0	1Ω	φ24
AKH-0.66/K-φ24-B	250~300A	1A	1.0	1.5Ω	φ24
